| The method of 3D modeling and grid subdivision for electromagnetic numerical simulation |
| Wei HE1,2, Wen-Li WU1,2, Jian-Hua LI1,2, Pin-Rong LIN1,2, Meng LIANG1,2, Guan-Wen GU1,2, Bin FENG1,2 |
1. Institute of Geophysical and Geochemical Exploration, Chinese Academy of Geological Sciences,Langfang 065000,China
2. Laboratory of Geophysical EM Probing Technologies,MLR,Langfang 065000,China |
|
|
|
|
Abstract Using some techniques such as computer graphics, human-computer interaction, and topological relation, the authors designed the process about the three-dimensional vector modeling under undulating topography, tetrahedron mesh generation, and hexahedral mesh generation. Through the study, the corresponding software module was developed. In the software, some tetrahedron mesh generation and hexahedral mesh generation utility tools can be provided to solve some related problems in MT. The efficiency of 3D electromagnetic method is improved in such fields as data management, model visualization and interpretation integration.
|
|
