| Geochemical characteristics of strata of Lower Cambrian Shuigoukou Formation in Southern Qinling and their implications for prospecting |
| Jun YOU1,2, Hong-Yuan CAO1, Feng-Jun ZHANG1, Wen-Chun CAI1, Jing-Chen LI1, Peng-Tao SHE1 |
1. Shaanxi Center of Geological Survey, Xi'an 710068, China
2. Shaanxi Institute of Geological Survey, Xi'an 710054, China |
|
|
|
|
Abstract The black rock series of the lower Cambrian Shuigoukou Formation exposed in Zhongcun-Xianghe area lies in the middle belt of Qinling area, and constitutes the typical strata of the black rock series and the main ore-bearing layer for gold and vanadium ore deposits in this area. The strata consist of a set of carbon, silica, argillite and carbonite formations, and the rocks include silicalite, carbonaceous silicalite, claystone, carbonaceous limestone, and carbonaceous-siliceous slate, which contain P-Mn nodules locally. Geochemical research on the strata reveals the following phenomena: Firstly, rocks are obviously rich in V, Au, Ag, Cu, Zn, Mo, Ni, Pt and Pd, and experienced intense differentiation and obvious superimposition-reformation, which was geochemically favorable for mineralization. Secondly, P-Mn nodules, claystones and silicalites are the most advantageous types of ore-bearing rocks. Thirdly, the values of ore-forming elements, especially V, Ni, Zn, Cu, Ag, U, PGE and the grade of ores are closely related to the content of carbon (TOC%) in the rocks. What's more, the distribution of deposits related to the black rock series of the Shuigoukou Formation is characterized by Au (Ag) in the western part and V in the eastern part, Au-V in the northern part and and Ag-V in the southern part. Grade of ores and content of carbon in rocks are featured by higher in the west and lower in the east, higher in the north and lower in the south, which indicates that the northern belt is much more favorable than the southern belt in prospecting, and that the western belt is more favorable than the eastern belt. These opinions are much significant for choosing the main and associated mineral types, indicators and ore-prospecting directions in further prospecting work in this area.
|
|
Received: 17 May 2017
Published: 04 June 2018
|
|
|
|
|
|
|
|
|
|
|
|
| 元素 | 最小值
Xmin | 最大值
Xmax | 平均值
| 标准离差
δ1 | 背景值
C0 | 标准离差
δ2 | 变化系数
Cv | 区域背景
X1 | 富集系数
k1 | 叠加强度
系数k2 | | V | 46 | 34969 | 3781 | 5105 | 105 | 40 | 1.4 | 70 | 54.0 | 4595 | | Co | 0.9 | 165.0 | 7.9 | 16.3 | 3.2 | 1.7 | 2.1 | 10.5 | 0.8 | 23.7 | | Au | 0.5 | 110.0 | 5.3 | 11.4 | 1.8 | 3.6 | 2.2 | 0.8 | 6.6 | 9.3 | | Ag | 0.02 | 7.97 | 1.91 | 1.52 | 1.91 | 1.52 | 0.8 | 0.05 | 38.2 | 1.0 | | U | 1.0 | 131.0 | 20.4 | 24.8 | 9.2 | 23.2 | 1.2 | | | 2.4 | | Cu | 10 | 1907 | 176 | 281 | 65 | 179 | 1.6 | 12 | 14.7 | 4.3 | | Pb | 1.0 | 257.0 | 24.8 | 30.8 | 10.4 | 3.3 | 1.2 | 11.3 | 2.2 | 22.3 | | Zn | 2 | 24516 | 507 | 2199 | 74 | 166 | 4.3 | 32 | 15.8 | 90.8 | | W | 0.4 | 12.5 | 2.3 | 2.1 | 1.4 | 0.5 | 0.9 | 1.1 | 2.1 | 6.9 | | Mo | 0.3 | 202.1 | 16.7 | 32.3 | 2.4 | 2.1 | 1.9 | 0.4 | 41.8 | 107 | | Ni | 11 | 2049 | 117 | 244 | 28 | 13 | 2.1 | 23 | 5.1 | 78.4 | | Ru | 0.03 | 4.36 | 0.67 | 0.9 | 0.37 | 0.4 | 1.3 | | | 4.1 | | Rh | 0.02 | 3.62 | 0.48 | 0.6 | 0.23 | 0.5 | 1.2 | | | 2.5 | | Pd | 0.02 | 159.70 | 22.07 | 28.4 | 9.57 | 28.5 | 1.3 | | | 2.3 | | Os | 0.01 | 24.44 | 2.30 | 3.4 | 0.29 | 0.2 | 1.5 | | | 134.8 | | Ir | 0.02 | 3.09 | 0.20 | 0.4 | 0.12 | 0.1 | 2.1 | | | 6.7 | | Pt | 0.01 | 48.06 | 6.45 | 7.8 | 1.00 | 0.6 | 1.2 | | | 83.9 |
|
|
|
| 元素 | 黏土岩类
(n=35) | 硅质岩类
(n=41) | 碳酸盐岩类
(n=14) | 炭硅质板岩类
(n=63) | 磷锰结核
(n=4) | 水沟口组
(n=149) | | TOC | 0.77 | 1.05 | 0.46 | 2.43 | 1.95 | 1.54 | | V | 4450 | 3494 | 1186 | 4158 | 3546 | 3781 | | Co | 13.1 | 5.3 | 5.5 | 7.5 | 9.5 | 7.9 | | Au | 9.4 | 5.9 | 2.0 | 3.3 | 4.1 | 5.3 | | Ag | 1.74 | 2.34 | 0.66 | 1.75 | 5.32 | 1.91 | | U | 20.4 | 16.7 | 7.1 | 21.4 | 76.1 | 20.4 | | Cu | 291 | 149 | 24 | 148 | 338 | 176 | | Pb | 29.6 | 20.1 | 12 | 27.6 | 34.7 | 24.8 | | Zn | 1328 | 301 | 90 | 169 | 2364 | 507 | | W | 2.7 | 2.1 | 2.1 | 2.4 | 2.1 | 2.3 | | Mo | 15.0 | 22.3 | 23.6 | 12.7 | 17.5 | 16.7 | | Ni | 186 | 90.5 | 48.6 | 86.8 | 531 | 117 | | Ru | 0.91 | 0.89 | 0.38 | 0.38 | 1.43 | 0.67 | | Rh | 0.76 | 0.52 | 0.12 | 0.35 | 0.90 | 0.48 | | Pd | 26.55 | 23.85 | 4.3 | 21.02 | 49.5 | 22.07 | | Os | 3.94 | 1.85 | 0.79 | 1.92 | 4.19 | 2.30 | | Ir | 0.24 | 0.33 | 0.13 | 0.07 | 0.52 | 0.20 | | Pt | 8.77 | 5.84 | 1.60 | 6.29 | 13.97 | 6.45 |
|
|
|
|
|
|
|
|
|
| [1] |
范德廉, 杨秀珍, 王连芳 , 等. 某地下寒武统含镍钼多金属黑色岩系的岩石学及地球化学特点[J]. 地球化学, 1973(3):143-164.
|
| [2] |
张爱云, 伍大茂, 郭丽娜 , 等. 海相黑色页岩建造地球化学与成矿意义[M]. 北京: 科学出版社, 1987.
|
| [3] |
涂光炽 . 初议中亚成矿域[J]. 地质科学, 1999,34(4):394-404.
|
| [4] |
刘春涌, 王永红 . 初论中亚黑色岩系型金矿床的基本特征——兼论新疆黑色岩系型金矿找矿方向[J]. 新疆地质, 2007,25(1):34-39.
|
| [5] |
张智勇 . 河南淅川下寒武统水沟口组黑色岩系沉积环境分析[D]. 郑州:河南理工大学, 2012.
|
| [6] |
杨宗镜 . 关于黑色岩系地质特征及其找矿的几个问题[J]. 西北地质, 1983(1):61-68.
|
| [7] |
杨剑 . 黔北地区下寒武统黑色岩系形成环境与地球化学研究[D]. 西安:长安大学, 2009.
|
| [8] |
肖启云, 李胜荣, 蔡克勤 . 湘黔下寒武统黑色岩系不同矿物组合中的铂族元素特征[J]. 中国地质, 2006,33(5):1083-1091.
|
| [9] |
张复新, 王立社, 侯俊富 . 秦岭造山带黑色岩系与金属矿床类型及成矿系列[J]. 中国地质, 2009,36(3):694-704.
|
| [10] |
高菊生, 王瑞廷, 张复新 , 等. 南秦岭寒武系黑色岩系中夏家店金矿床地质地球化学[J]. 中国地质, 2006,33(6):1371-1378.
|
| [11] |
王立社, 侯俊富, 张复新 , 等. 北秦岭庙湾组黑色岩系稀土元素地球化学特征及其成因意义[J]. 地球学报, 2010,31(1):73-82.
|
| [12] |
王立社, 张复新, 侯俊富 , 等. 秦岭山阳水沟口组黑色岩系微量元素地球化学及其沉积成矿背景的指示意义[J]. 中国地质, 2012,39(2):311-325.
|
| [13] |
侯俊富 . 南秦岭下寒武统黑色岩系中金—钒成矿特征及成矿规律[D]. 西安:西北大学, 2008.
|
| [14] |
王立社 . 陕西秦岭黑色岩系及其典型矿床地质地球化学与成矿规律研究[D]. 西安:西北大学, 2009.
|
| [15] |
朱红周, 侯俊富, 王淑利 . 南秦岭千家坪钒矿床地质地球化学特征与钒的富集规律[J]. 中国地质, 2010,37(5):1490-1500.
|
| [16] |
王聚杰, 曾普胜, 麻菁 , 等. 黑色岩系及相关矿产——以扬子地台为例[J]. 地质与勘探, 2015,51(4):677-689.
|
| [17] |
张国伟, 董云鹏, 姚安平 . 秦岭造山带基本组成与结构及其构造演化[J]. 陕西地质, 1997,15(2):1-14.
|
| [18] |
Yan Z, Wang Z Q, Yan Q R , et al. Devonian sedimentary environments and provenances of the Qinling orogen: Constrains on Late Paleozoic southward accretion of the North China cration[J]. International Geology Review, 2006,48(7):585-618.
|
| [19] |
张锋军, 蔡文春, 李景晨 , 等. 陕西省山阳中村—商南湘河一带基础地质成果报告[R]. 西安:陕西省地质调查中心, 2017.
|
|
|
|
