Strategy of static correction in complicated mountainous area on the south margin of Junggar Basin |
Yi-Wen LIU, Yong LUO, Li-Li YIN, Qi GUO |
Geophysical Research Center,Research Institute of Exploration and Development,Xinjiang Oilfield Company,PetroChina,Urumqi 830013,China |
|
|
Abstract The dramatic changes of near-surface velocity and vertical as well as lateral thicknesses that result from complicated lithologies and structures in the mountain areas and mountain front of the southern margin of Junggar basin bring great difficulties to the static correction in this area.For the purpose of solving the problem of seismic data imaging in mountain areas,high-frequency time difference between seismic traces must be eliminated to avoid out-of-phase stacking,and medium-long wave length components in static correction must be controlled to ensure the accuracy of the structure location and structural height.The application conditions and adaptability of existing static correction methods were analyzed and studied to improve imaging quality in the mountain areas of the southern margin.A new set of ideas for decomposition and reconstruction of long and short wavelength components were presented according to static correction values,the advantages of different static correction methods could be taken and good effect was obtained in the mountain areas on the southern margin of the Junggar basin.
|
Received: 16 March 2018
Published: 19 December 2018
|
|
|
|
|
[1] |
郑鸿明, 吕焕通, 娄兵 , 等. 地震勘探近地表异常校正[M]. 北京: 石油工业出版社, 2009: 7-14.
|
[2] |
薛为平, 其其格, 梁英 , 等. 折射延迟时与时深曲线反演模型法静校正技术[J]. 新疆地质, 2011,29(1):249-251.
|
[3] |
王彦春, 余钦范, 段云卿 , 等. 折射波静校正方法在复杂地表地区的应用[J]. 物探与化探, 1999,23(6):428-434.
|
[4] |
文雪康, 刘胜, 李世琼 , 等. 层析法在黄土塬区近地表结构调查中的应用[J]. 物探与化探, 2012,36(5):766-771.
|
[5] |
邓志文 . 复杂山地地震勘探[M]. 北京: 石油工业出版社, 2006: 4-7.
|
[6] |
薛为平, 梁英, 刘治凡 . 准噶尔盆地特殊地表的静校正应用[J]. 新疆地质, 2005,23(1):82-85.
|
[7] |
张亚斌, 杜贤, 孔剑冰 , 等. 复杂山地低信噪比地震资料处理方法[J]. 物探与化探, 2005,29(1):34-36,40.
|
[8] |
刘江平 . 地震共中心点道集的瞬时基准面静校正和动校正[J]. 物探与化探, 1997,21(1):15-22.
|
[9] |
尹奇峰, 潘冬明, 夏暖 , 等. 地表一致性静校正量误差分析[J]. 物探与化探, 2011,35(6):785-788.
|
[10] |
刘玉柱, 董良国 . 初至波层析影响因素分析[J]. 石油地球物理勘探, 2007,42(5):544-553.
|
[11] |
韩晓丽, 杨长春, 麻三怀 , 等. 复杂山区初至波层析反演静校正[J]. 地球物理学进展, 2008,23(2):475-483.
|
[12] |
林伯香, 孙晶梅, 徐颖 , 等. 复杂地表条件静校正中的3D表层速度层析反演研究[J]. 石油物探, 2005,44(5):454-457.
|
[13] |
林伯香, 肖万富, 李博 , 等. 层析静校正在黄土塬弯宽线资料处理中的应用[J]. 石油物探, 2007,46(4):417-420.
|
[14] |
李敏杰, 刘玉增, 孟祥顺 , 等. 陕北富县黄土塬区三维地震资料处理技术[J]. 石油物探, 2012,51(3):285-291.
|
[15] |
杨文军, 段云卿, 姜伟才 , 等. 层析反演静校正[J]. 物探与化探, 2005,29(1):41-43.
|
[16] |
李锋, 曾庆才, 吕金博 , 等. 西部复杂地区地震资料处理方法[J]. 物探与化探, 2004,28(2):159-163.
|
[17] |
何新贞, 尚新民, 王常波 , 等. 复杂地表及地下地质条件下地震资料处理中的若干重要环节[J]. 物探与化探, 2004,28(5):453-456.
|
[18] |
侯建全, 王建立, 孟小红 . 适合于复杂地表条件下静校正处理技术[J]. 物探与化探, 2002,26(4):307-311.
|
[19] |
刘连升 . 约束初至拾取与初至波剩余静校正[J]. 石油地球物理勘探, 1998,33(5):604-610.
|
[20] |
李录明 . 动校前初至波自动剩余静校正[J]. 石油地球物理勘探, 1989,24(2):179-186.
|
|
|
|
