基于电阻率测井曲线的大地电磁测深标定

doi:10.11720/wtyht.2022.1494

Abstract
Figure/Table
References
Related Citation (15)

Download: PDF (2643 KB) HTML (0 KB)
Export: BibTeX | EndNote (RIS)

Abstract

The distortion correction of magnetotelluric sounding curves is critical to magnetotelluric exploration. Based on the comparison between the resistivity logging curves of basin D and the basin's inversed sounding curves before and after being corrected through magnetotelluric sounding translation, this study constructed a transformation function and calibrated magnetotelluric sounding curves using logging curves. The magnetotelluric inversion results improved using the calibration technology proposed in this study are highly consistent with the verification boreholes. Finally, this study effectively revealed the structural characteristics of basin D by combining drilling, seismic, gravitational, and magnetic data.

Key words： logging curve magnetotelluric sounding calibration transformation function

Received: 03 September 2021 Published: 21 June 2022

ZTFLH:

P631
